BLACK DC-063 Power socket is stable, reliable and durable

Short Description:

Product model: DC-063
Metal material: Copper
Shell material: PPA nylon
Current: 1A
Voltage: 12V
Color: Black
Temperature range: -30~70℃
Withstand voltage: AC500V(50Hz) /min
Contact resistance: ≤0.03Ω
Insulation resistance: ≥100MΩ
Inserting and pulling force: 3-20N
Life span: 5,000 times


Product Detail

Product Tags

Product characteristics

1. The bearing power of DC power socket is large, and the socket is not prone to fever and other phenomena.
2. The inner core of the socket is made of high temperature resistant plastic material, and the DC power socket is not easy to deform at high temperature.
3. Reasonable structure design, large plug distance, each plug of DC power socket can be used independently, will not affect each other.
4 Socket shrapnel using high elastic phosphorus copper data, plug and pull times without fatigue, touch outstanding is not easy to show sparks.

The DC-063 power socket has high stability and reliability, which can ensure the long-term stable operation of DC power supply equipment. Its output voltage is stable, in line with international standards, and passed the CE certification, with a high degree of safety and reliability.

The mechanical properties of the DC-063 power socket are also excellent. The plug is made of high quality material, which has a long life and will not be damaged by repeated plugging. Socket body adopts engineering plastic design, wear-resistant and non-aging. Plug and socket after insertion close contact, circuit connection is stable and reliable.

Product drawing

2

Application scenario

Video and audio products, notebook, tablet, communication products, household appliances
Security products, toys, computer products, fitness equipment, medical equipment
Mobile phone stereo design, earphone,CD player, wireless phone, MP3 player, DVD, digital products
The DC-063 power outlet also has a wide range of applicability. It is suitable for various specifications of DC power supply equipment, such as LED lighting, security monitoring, communication equipment, etc. At the same time, it is also suitable for home intelligent control, industrial control and other fields.

In short, DC-063 power socket has the advantages of stability, reliability, durability and wide applicability. It is a cost-effective DC power supply equipment, which is deeply loved by users.
