DC085 Copper and gold black power socket

Short Description:

Product model: DC-085
Metal material: Copper/gold
Shell material: PPA nylon
Current: 1A
Voltage: 12V
Color: Black
Temperature range: -30~70℃
Withstand voltage: AC500V(50Hz) /min
Hole size: Φ2.0Φ2.5
Contact resistance: ≤0.03Ω
Insulation resistance: ≥100MΩ
Inserting and pulling force: 3-20N
Life span: 5,000 times


Product Detail

Product Tags

Product characteristics

1. The bearing power of DC power socket is large, and the socket is not prone to fever and other phenomena.
2. The inner core of the socket is made of high temperature resistant plastic material, and the DC power socket is not easy to deform at high temperature.
3. Reasonable structure design, large plug distance, each plug of DC power socket can be used independently, will not affect each other.
4 Socket shrapnel using high elastic phosphorus copper data, plug and pull times without fatigue, touch outstanding is not easy to show sparks.

Product drawing

2

Application scenario

Video and audio products, notebook, tablet, communication products, household appliances
DC power outlet The DC-085 is a power outlet that uses direct current and can be connected to a variety of devices, such as lamps, fans, and mobile phones. The socket, which consists mainly of an internal circuit and an external plug, looks similar to a regular electrical outlet, but it provides direct current, which sets it apart from a regular outlet. Compared with AC power sockets, DC power sockets have more stable and safer current, which is more suitable for some electrical equipment. Therefore, it is widely used in various scenarios that require DC power.

First, the DC-085 is widely used in home scenarios, such as televisions, sound systems, routers and other devices. These devices require DC power, and the DC-085 socket provides efficient and stable power.

Secondly, DC-085 is also used in industrial fields, such as automotive electronics, aviation and aerospace industries. In these fields, the demand for DC power is great, DC-085 has become one of the important equipment to provide DC power.

In addition, the DC-085 is also widely used in outdoor activities and expeditions, as AC power is not available in these environments, and electrical equipment that requires batteries requires the DC-085 and other DC outlets for charging. For example, outdoor lights, tablets and other devices all require DC-085 and other DC outlets to charge.

In short, DC-085 has a wide range of applications and can meet the DC power needs of various equipment. In addition, because of the advantages of DC power, more and more people will choose to use DC power sockets to provide power for electrical equipment.
