IF-FM8-3457-32-500A

Short Description:

Product Model:IF-FM8-3457-32-500A

Material:PA66/T2 RED COPPER

Current:500A

Voltage: 0-600V AC

Dielectric strength:3000V

Opening size:Φ25.4-Φ4.5*2(44mm)

Screw diameter: Copper column outer diameter Φ17.5, thread inner diameter M8

Mounting screw:M4*16mm

Color: red/black


Product Detail

Product Tags

Product characteristics

Wiring column thread depth: In order to effectively avoid the phenomenon of slippery wire in the process of use, the thread depth to 15.7mm. let the connection voltage line more solid, not easy to loosen, to eliminate hidden problems.
PA66 material: 1, has good insulation and dielectric properties, the use of safe and secure. 2, has a good heat resistance to aging, flame retardant.
Tin plating process: with high chemical stability and good electrical conductivity.
Sealing gasket: In the case of screw tightening, it can make the sealing between the product and the plate better.


Product Drawing


Application Scenario

Widely used in energy storage, batteries, storage cabinets, high-current machines and equipment, and other scenarios


Physical picture display
