M23 2+1+5 Electric Bike Scooter Male Female Plug Socket Power Connector
M23 Electric Bike Scooter Male Female Plug Socket Power Connector e Bike Plug Batteries Scooter E-Bike Battery Connector 30A
Rated: DC300V 30A
Temperature: -25 ~ 70 ℃
Contact resistance: ≤10mΩ
Insulation resistance: ≥ 100mΩ
Pressure: AC2000V (50 Hz) 1 min
Insertion and removal force: 20~60N
Life span: 3000 times
Salt spray test: 72 hours
Packing & Delivery
Packing
1: Neutral packing: Bulking packing in Poly bag +inner box +carton
2: Upon customers' request
Payment & Delivery
Payment: TT,LC, Western Union, Money Gram, PayPal etc., T/T 30% as deposit and the balance before delivery. We'll show you the photos of the products and packages.
Delivery time: 7-10 working days after the payment confirmed.
Shipment: Ship worldwide by sea, air, express delivery, like DHL, UPS, TNT and FEDEX etc.
