MR30PW-M Connector Plug With Sheath For Twister

Short Description:


Product Detail

Product Tags

Product Parameter

Product Model: MR30PW-M

Rated Current: 20A MAX(△<85℃)

Voltage Resistance: 500V DC

Insulation resistance: ≥2000MΩ

Contact resistance: ≤1.2MΩ

Mechanical life: 100times

Salt Spray: 48h

Protection level: IP40

Operational Temperature: -20℃~120℃

Flame Retardant Rating: UL94 V-0

Outer Hull: PA, YELLOW

Pinhole: Aldary,Elecreoplate: Gold Plating

Product characteristics

1. MR30PW-M is a horizontal injection molded 3PIN connector, for the horizontal space PCB board to provide integrated solutions, and the motor can be perfectly combined, integrated, for the current power lithium power plug-in standard parts, another line to line design.

2. It is applicable to the board-to-board or wire-to-board connection between lithium batteries and controllers.

Announcements

Please do not exceed the rated current and voltage when in ues.

Don’t use it when external forces are applied to the connector.

Don’t use it in a place with high temperature and humidity.

When opening the package, be careful to prevent deformation, bending, or ejecting of terminals.

Product Drawing

MR30PW-M

Application Areas

2

Telecontrolled aircraft

telecar

Remote control ship

Unicycle

3

Electric vehicle

UAV

Traversal machine

Solar lamp

1

Balancing car

Electric scooter

Solar lamp
