New Fashion Design for China Wnre Push Button Switch Kcd-1200 Waterproof Rocker Switch

Short Description:

Model Number: ND2+6 and ND2+0

Product Name: ND electric car portable charging and discharging waterproof plug

Gender: Female / Male

Sustained current: 30-50A

Contact material: Brass with Silver/ Gold Plating

Operation Temp: -30℃ ~ +70℃

Waterproof: IP67

Application: Sharing electric bikes/motorcycles,new energy vehicles, high-probability charging piles, etc


Product Detail

Product Tags

Our progress depends about the advanced products ,fantastic talents and continuously strengthened technology forces for New Fashion Design for China Wnre Push Button Switch Kcd-1200 Waterproof Rocker Switch, We warmly welcome all perspective inquiries from home and abroad to cooperate with us, and look forward to your correspondence.
Our progress depends about the advanced products ,fantastic talents and continuously strengthened technology forces for China Rocker Switch, Toggle Switch, In the increasingly competitive market, With sincere service high quality products and solutions and well-deserved reputation, we always offer customers support on items and techniques to achieve long-term cooperation. Living by quality, development by credit is our eternal pursuit, We firmly believe that after your visit we’ll become long-term partners.

rocker switchtact switch
toggle switchmetal push button switch

Advantage:
Most of our products are CE UL CCC certificated. We specialized in producing and design Rocker switches for more than 20 years.
We do OEM of 1Waterproof 2Base type 3Body color 4Rocker color 5Actuator shape 6Making 7Position 8Terminal Current to satisfy your requirement.

Usage Range:
Rocker switch is a kind of small high capacity power switch which is suitable for household appliances and office equipment. Compared with other switches, it is more powerful. Please communication with us about your require rated current in order to stop overloading issue. And please avoid water if the switch without waterproof function. Two ways of design To reach waterproof function: by compact or waterproof cap.

Tech Specifications

Description Product Attribute
Manufacturer WNRE
Actuator Rocker
Color Black
Contact Form DPDT
Contact Plating Silver
Contact Rating 20 A
Current Rating 20 A
Illuminated Illuminated
Illumination Color Green, Amber
LED Supply Voltage 12 VDC
Lamp Type LED
Maximum Operating Temperature + 85 C
Minimum Operating Temperature - 40 C
Mounting Style Panel
Mounting Type Bracket
Product Rocker Switches
Product Type Rocker Switches
Series KCD
Switch Function (ON) – OFF – (ON)
Termination Style Quick Connect
Tradename Contura II & III
Type Snap-In Rocker Switch
Voltage Rating DC 12 VDC



Export and Environmental Classification

ECCN   EAR99
HTS   8536509065
RoHS Compliant   Yes
RoHS Exemption Number   N/A
Lead(PB) in Terminals   No
REACH SVHC   No
REACH Substance Name   N/A



1

Rocker switch is a kind of small high capacity power switch which is suitable for household appliances and office equipment. Compared with other switches, it is more powerful. However, there are different types of rocker switches.

1. Small capacity unsealed

The rated voltage and current of this kind of ship type switch are small, 5A @ 120VAC, 28vdc; 2A @ 250VAC. This kind of product has three positions. In terms of material, its terminal is usually brass covered with gold or silver. Long life, up to 50000 times.

Electrical Ratings 5A @ 120VAC, 28VDC;2A @ 250VAC

Electrical Life 50,000 cycles typical

Contact Resistance < 30 mΩ max initial @ 2-4VDC, 100mA

Dielectric Strength 1500Vrms min

Insulation Resistance > 100MΩ min

Operating Temperature -40°C to 85°C

Storage Temperature -40°C to 85°C

2. Large capacity sealed type

For the large capacity ship type switch, it is more suitable for use in the power supply, and the sealing safety is more guaranteed, 15A @ 125VAC; 8A @ 250VAC, with two gears, on or off, and the terminal material is brass tin clad.

Electrical Ratings 15A @ 125VAC;8A @ 250VAC

Electrical Life 10,000 cycles typical

Contact Resistance < 50 mΩ initial

Dielectric Strength 1500Vrms min

Insulation Resistance > 100MΩ min

Operating Temperature -40°C to 85°C

Storage Temperature -40°C to 85°C

Our progress depends about the advanced products ,fantastic talents and continuously strengthened technology forces for New Fashion Design for China Wnre Push Button Switch Kcd-1200 Waterproof Rocker Switch, We warmly welcome all perspective inquiries from home and abroad to cooperate with us, and look forward to your correspondence.
New Fashion Design for China Rocker Switch, Toggle Switch, In the increasingly competitive market, With sincere service high quality products and solutions and well-deserved reputation, we always offer customers support on items and techniques to achieve long-term cooperation. Living by quality, development by credit is our eternal pursuit, We firmly believe that after your visit we’ll become long-term partners.
