How should we pay attention in the process of using the metal push button switch.
(1) The button should be checked frequently to remove the dirt on it. Because the distance between the contact of the button is small, after years of use or sealing is not good, dust or oil emulsion of each order inflow, will cause insulation reduction and even short circuit accident. In this case, insulation and cleaning treatment must be carried out, and corresponding sealing measures must be taken.
(2) When the button is used in high temperature occasions, it is easy to make the plastic deformation and aging, resulting in the loosening of the button and causing the collision between the wiring screws and short circuit. According to the situation, a fastening ring can be added to tighten the installation, and insulating plastic pipe can be added to the wiring screw to prevent loosening.
(3) The button with the indicator light is difficult to replace because the bulb will be hot and the plastic lampshade will be deformed for a long time. Therefore, it should not be used in the place with longer power time; If you want to use, you can properly reduce the voltage of the bulb, prolong its service life.
(4) If poor contact is found, the reason should be identified: if the contact surface is damaged, it can be trimmed with a fine file; If there is dirt or soot on the contact surface, it is appropriate to wipe clean with a clean cotton cloth dipped in solvent; If the contact spring fails, it should be replaced; If the contact is seriously burned, the product should be replaced.
(5) It is strictly prohibited to scrub the electric control panel with water to prevent damage to the instrument.
(6) metal button switch quality is assembly process, assembly management ability, staff quality meaning and quality assurance ability and other factors to determine, different guarantee ability out of the product quality must be different, now the market assembly method has manual and machine, because the current automation ability to improve, so each has advantages and disadvantages: The machine assembly cost is low but the product quality is low, the manual assembly cost is high but the quality is also high.
(7) When the metal button switch is pressed, the two pairs of contacts act at the same time, the normally closed contact is disconnected, and the normally open contact is closed. In order to indicate the function of each button and avoid misoperation, the button cap is usually made into different colors to show the difference. The colors are red, green, black, yellow, blue, white and so on.
I hope that through today’s introduction, we can help you to use the button switch more safely!
