XT120 (2+2)-M 60A Large Current Battery Connector

Short Description:


Product Detail

Product Tags

Product Parameter

Product Model: XT120(2+2)-M

Rated Current: 60A MAX(8AWG△<85℃);

Voltage Resistance: 500V DC

Insulation resistance: ≥2000MΩ

Contact resistance: ≤1.0MΩ

Mechanical life: 100times

Salt Spray: 48h

Protection level: IP40

Operational Temperature: -20℃~120℃

Flame Retardant Rating: UL94 V-0

Outer Hull: PA, YELLOW

Pinhole: Aldary,Elecreoplate: Gold Plating

Product characteristics

1. XT120(2+2)-M is an anti-spark 180° outgoing welded injection molded 2+2PIN connector with rear cover and internal connector with lithium power supply.

2. It can apply to the wire-to-wire connection scenario between lithium batteries and controllers.

Announcements

When in use, please note the voltage and current.

Do not use it when external forces are applied to the connector.t

When opening the package, please be carefully.

Please strictly follow the requirements of the specification of the using environment.

Application Areas

2

Telecontrolled aircraft

telecar

Remote control ship

Unicycle

3

Electric vehicle

UAV

Traversal machine

Solar lamp

1

Balancing car

Electric scooter

Solar lamp
