XT60L-M Plug Connector Set with sheath
Product Parameter
Product Model: XT60L-M
Rated Current: 35A MAX（12AWG△＜85℃）
Voltage Resistance: 500V DC
Insulation resistance: ≥2000MΩ
Contact resistance: ≤1.0MΩ
Mechanical life: 100times
Salt Spray: 48h
Protection level: IP40
Operational Temperature: -20℃~120℃
Flame Retardant Rating: UL94 V-0
Outer Hull: PA, YELLOW
Pinhole: Aldary，Elecreoplate: Gold Plating
Product characteristics
1. XT60L-M is a 180° out-line welded injection molded 2PIN with lock connector, optional rear cover, for the current power lithium power plug-in standard parts, another wired plate design.
2. Apply to the wire-to-wire connection scenario between lithium batteries and controllers.
Announcements
Excessive voltage or current may be the cause of the fault, please unplug and plug in devices without power.
Do not use this goods when external forces are applied to the connector.
Do not use it in a hot place.
When opening the package, be careful to prevent deformation, bending, or ejecting of terminals.
Product Drawing
Application Areas
Telecontrolled aircraft
telecar
Remote control ship
Unicycle
Electric vehicle
UAV
Traversal machine
Solar lamp
Balancing car
Electric scooter
Solar lamp
