XT90PW-M Connectors Plug For PCB Board Connect Parts
Product Parameter
Product Model: XT90PW-M
Rated Current: 45A MAX（△＜85℃）
Voltage Resistance: 500V DC
Insulation resistance: ≥2000MΩ
Contact resistance: ≤1.0MΩ
Mechanical life: 100times
Salt Spray: 48h
Protection level: IP40
Operational Temperature: -20℃~120℃
Flame Retardant Rating: UL94 V-0
Outer Hull: PA, YELLOW
Pinhole: Aldary，Elecreoplate: Gold Plating
Product characteristics
1. XT90PW-M is a vertical injection molded 2PIN connector, which provides an integrated solution for the PCB board with longitudinal space. It is a standard part of the current power lithium power supply.
2. It may applicable to the wire-to-board or board-to-board connection between lithium batteries and controllers.
Announcements
When in use, do not exceed the rated current and voltage.
Do not use it when external forces are applied to the connector.
Do not use it in a place with high temperature and humidity.
Please be careful when using it.
Product Drawing
Application Areas
Telecontrolled aircraft
telecar
Remote control ship
Unicycle
Electric vehicle
UAV
Traversal machine
Solar lamp
Balancing car
Electric scooter
Solar lamp
